CE Plumbing Systems 1.5 Inch Brass Ball Valve ISO 228 Threaded
Product Details:
| Place of Origin: | China |
| Brand Name: | TASAN |
| Certification: | CE |
| Model Number: | 15D |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | TASAN Standard Packing |
| Delivery Time: | 8 working Days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 70000pcs Per Week |
|
Detail Information |
|||
| Product Name: | Brass Ball Valve | Material: | Brass |
|---|---|---|---|
| Port Size: | 1/4"-11/4" | Connection Type: | Female X Male |
| Working Temperature Min./Max.: | –20°C ~150°C (-4°F~302°F) In Absence Of Steam | Pressure Rating:: | PN40/600psi -- 1/4"~1";PN25/360psi --11/4"~2" (DN32~50mm) |
| Thread: | ISO 228「equivalent To DIN EN 10226-1 And BS21」 | Power: | Manual |
| High Light: | CE 1.5 Inch Brass Ball Valve,Plumbing Systems Brass Ball Valve,Plumbing Systems Ball Valve Threaded |
||
Product Description
15D Brass Water Ball Valve, Full Flow
15 series BV is the excellent quality design for High-low temperature & High pressure conditions, suitable for domestic and commercial plumbing system, industrial application, sanitary, heating & air-condition system, pneumatic systems, waterworks, oil pipelines, gasoline network, saturated steam, used for non-aggressive fluid only.
● Pressure rating:
PN40/600psi -- 1/4"~1" (DN8~25mm)
PN25/360psi --11/4"~2" (DN32~50mm)
● Working temperature Min./Max.:
–20°C ~150°C (-4°F~302°F) in absence of steam
● Descriptions:
Full Flow(1/4 turn to open and close)
Nickel-plated Forged brass body
Chrome-plated Machined brass/S.S. ball *
Double 0-ring safe stem -PTFE ball seats(1/4" and 3/8")
TASAN Blowout-proof stem - Minimal 10000 times of use
Designed with adjustable gland and EPDM O-ring(1/2"~4")
TASAN Professional-Antirust handles with S.S. handle screw
Threads: ISO 228「equivalent to DIN EN 10226-1 and BS21」
● Structure Charts
| Part Code | Size | A/mm | B/mm | C/mm |
| 15DNS301 | 1/4’’ | 39 | 35 | 52 |
| 15DNS302 | 3/8’’ | 40 | 35 | 52 |
| 15DNS303 | 1/2’’ | 45 | 37 | 52 |
| 15DNS304 | 3/4’’ | 51 | 42 | 56 |
| 15DNS305 | 1’’ | 59 | 48 | 65 |
| 15DNS306 | 11/4’’ | 69 | - | 65 |
| 1 | Body | High-density Forged Brass |
| 2 | Seats | Pure PTFE (Polytetrafluoroethylene) |
| 3 | Ball | Forged Brass/S.S.* |
| 4 | Body Cap | Forged Brass |
| 5 | Stem | Machined Brass Rod/S.S.* |
| 6 | O-ring | EPDM 70 Shore |
| 7 | Gland Packing | Pure PTFE (Polytetrafluoroethylene) |
| 8 | Gland | Machined Brass Rod |
| 9 | Lever Handle | Z.P. Steel Varnished, PVC Sleeve |
| 10 | Screw Nut | Stainless Steel |
| 11 | T Handle | Aluminum |
| 12 | Name Plate | POM |
| 13 | Handle Screw | Nickel-plated Steel |
The thread, color of handle, materials, etc. can be customized.
● Certificates
● Company Profiles
TASAN,one of the best worldwide brand of Flow Tech products. Manufacturing with the glorious history over 30 years, We promise to customers the 7 years quality warranty and the cooperation with the best known insurance company PICC for international quality accident. Ensure the most cost-effective products and safeguard service for our agents worldwide. Our success lies in the satisfaction of each of our valued customers.
TASAN,insisting 100% original own-design,Long-term strategic partnership with the famous European valve manu facturers and the registered laboratories for R&D and testing.
TASAN,has an excellent international team of marketing.
Join in TASAN, we must be your best choice.
● Tasan's Motto
We Never Stop Pursuing Perfection
● Tasan's Products:
Valvas And Fittings For Construction Work And Industrial Equipment,Sanitary Ware.
● Tasan's Market:
Overseas And Domestic
● Tasan's Sales Methods:
BRAND Agency,OEM,ODM
● Factory Construction Area:
900.000 Sq.ft.
● Research And Development Team:
20 Research And Design Specialists.
● SALES NETWORK
More Than 45 Countries Including The US, Canada, Germany, the Uk, The Netherlands,ltaly, Russia,dubai
● Our Package Details
TASAN logo forged in valve body.
TASAN logo stamped or printed on handle.
Inner box material is a 3-layer corrugated bond paper, with clear & attractive printing.
PE plastic ECO bag.
Product spec. label sticked on the side of master carton.
TASAN special packing tape.
Master carton material is a 5-layer corrugated bond paper, with clear & attractive printing.
● FAQ
Q: How long is your product guarantee period?
A: We have Seven-year guarantee and 24 hours full-time service.
Q: What is your MOQ?
A: We have no MOQ. We have a large warehouse and we promise "Instant Order, Immediate Delivery and No MOQ".
Q: Can you accept OEM and ODM?
A: TASAN has our own BRAND Agency. OEM and ODM do as well
Q: How long is your delivery time?
A: For the items if we have enough stocks, we can send to you immediately. For mass production, we can promise 30-35 days.
